| SYSTEM | |
| COMPRESS | STANDARD H.264 HIGH PROFILE. |
| CPU | CORTEX A9. |
| OSD | EMBEDDED LINUX. |
| VIDEO | |
| VIDEO INPUT | BNC X 8. |
| RESOLUTION | AHD : 4MP, 3MP, 1080P, 720P, WD1 REAL TIME. |
| OUTPUT | HDMI X 1 : 4K X 2K, VGA X 1 : 1920 X 1080, BNC X 1 : CVBS (USED AS SPOT OUTPUT). |
| AUDIO | |
| INPUT | RCA X 1. |
| OUTPUT | RCA X 1. |
| 2 - WAY AUDIO | TAKE UP CHANNEL ONE AUDIO INPUT. |
| RECORD | |
| RESOLUTION | 4MP, 3MP, 1080P, 720P, WD1. |
| FRAME RATE (fps) | 4MP/ 3MP : 12 fps (PAL)/ 15 fps (NTSC), 1080P/ 720P/ WD1 : 25 fps (PAL)/ 30 fps (NTSC). |
| BIT RATE | 768 Kbps ~ 8 Mbps. |
| MODE | MANUAL, TIMER, MOTION, SENSOR. |
| FLIE MANAGER | LOCK, UNLOCK. |
| PLAY BACK | |
| PLAY BACK | 8 CH. |
| SEARCH | TIME SLICE/ TIME/ EVENT/ TAG SEARCH. |
| SMART SEARCH | HIGHLIGHTED COLOR TO DISPLAY THE CAMERA RECORD IN A CERTAIN PERIOD OF TIME, DIFFERENT COLORS REFERR TO DIFFERENT RECORD EVENTS. |
| FUNCTION | PLAY, PAUSE, FF, FB, DIGITAL ZOOM etc. |
| ALARM | |
| MODE | MANUAL, SENSOR, MOTION, EXCEPTION. |
| INPUT | NO |
| OUTPUT | NO |
| TRIGGERING | RECORD, SNAP, PRESET, E-MAIL, etc. |
| NETWORK | |
| INTERFACE | RJ 45 10M/ 100M X 1. |
| PROTOCAL | TCP/ IP, PPPOE, DHCP, DNS, DDNS, UPnP, NTP, SMTP. |
| WEB CLIENT | MULTIPLE USERS ONLINE. |
| MOBILE DEVICE | |
| OS | iPHONE, ANDRIOD. |
| STORAGE | |
| HDD | SATA X 1, MAX. 6TB. |
| BACKUP | |
| LOCAL BACKUP | U DISK, USB MOBILE HDD. |
| NETWORK BACKUP | YES. |
| PORT | |
| RS 485 | RS 485 X 1, CONNECT TO PTZ OR KEYBOARD. |
| USB INTERFACE | USB 2.0 X 1, (FRONT PANEL), USB 3.0 X 1 (REAR PANEL). |
| REMOTE CONTROLLER | YES. |
| OTHERS | |
| POWER SUPPLY | DC 12V. |
| CONSUMPTION | ≤ 15W (WITHOUT HDD). |
| DIMENSION (W X D X H) | 300 X 248 X 52 (W X D X H). |
| WORKING ENVIRONMENT | -10 ~ 50°C, 10% ~ 90% HUMIDITY. |
